About This Architecture

Two-tier web application architecture running PHP 8.4 on server 10.23.100.29:183 with MySQL database backend at 10.23.100.18:3306. Users connect directly to the Winforce Application PHP layer, which handles business logic and queries the Winforce Database MySQL instance over the internal network. This classic client-server pattern demonstrates separation of presentation and data tiers, common in enterprise PHP applications requiring straightforward deployment and maintenance. Fork this diagram on Diagrams.so to customize IP addresses, add load balancers, or document your own PHP application topology. Export as .drawio, .svg, or .png for technical documentation and runbooks.

People also ask

How do I diagram a two-tier PHP application with MySQL database?

A two-tier PHP MySQL architecture separates the web application layer (PHP 8.4 on 10.23.100.29:183) from the data layer (MySQL on 10.23.100.18:3306). Users connect to the PHP server, which queries the database over the internal network, as shown in this Winforce application diagram.
