About This Architecture

Multi-role sequence diagram for a jewelry automation platform orchestrating real-time gold pricing, retailer margin configuration, wholesaler B2B networks, and workshop repair cycles on AWS. The architecture flows through four phases: continuous live gold price feed, retailer B2C sales with inventory sync, wholesaler invite-based B2B catalog sharing, and workshop order processing with real-time synchronization. Each role—retailer (Kuyumcu), wholesaler (Toptanci), workshop (Atolye), and physical customer—interacts through synchronous calls and asynchronous real-time sync events managed by a central sync engine. This pattern demonstrates how to build role-based, multi-channel jewelry commerce with live commodity pricing and distributed inventory management. Fork and customize this diagram on Diagrams.so to adapt the sequence flows, add additional roles, or integrate your own AWS services like Lambda, SQS, or DynamoDB for state management.

People also ask

How do you design a multi-role jewelry e-commerce platform on AWS that handles live gold pricing, B2B wholesaler networks, and workshop repair cycles with real-time inventory sync?

This diagram shows a four-phase sequence architecture: Phase 0 feeds live gold prices continuously, Phase 1 enables retailer B2C sales with margin configuration, Phase 2 manages wholesaler B2B invites and custom pricing via virtual catalog, and Phase 3 orchestrates workshop repair orders. A real-time sync engine coordinates asynchronous updates across inventory, catalog, and transaction systems, a
