About This Architecture

GCP Apigee multi-cloud platform integrating Google Cloud and Oracle Cloud Infrastructure through hybrid connectivity and centralized API governance. Traffic flows from internet clients through Cloud Armor DDoS/WAF protection and external load balancers into a GCP VPC spanning DMZ, Apigee runtime, GKE private, and connectivity subnets, with Apigee API Platform and Sense providing API management and threat detection across Springboot microservices. Hybrid connectivity via Cloud VPN Gateway and Dedicated Interconnect links the GCP platform to an on-premises Edarat data center and OCI me-jeddah-1 region, where OKE clusters and Oracle Autonomous Database extend the architecture. Cloud Monitoring, Logging, IAM, and KMS provide observability and security across all layers. Fork this diagram to customize subnets, add regions, or adjust firewall rules for your multi-cloud API strategy.

People also ask

How do you design a multi-cloud API management platform spanning GCP, OCI, and on-premises data centers with secure hybrid connectivity?

This diagram shows a GCP Apigee-centric multi-cloud platform with Cloud Armor and external load balancers protecting internet traffic, Apigee API Platform and Sense managing APIs across GKE microservices, and hybrid connectivity via Cloud VPN and Dedicated Interconnect linking to OCI me-jeddah-1 region and on-premises Edarat data center. Cloud Monitoring, Logging, IAM, and KMS provide unified obse
