About This Architecture

Event-driven emergency security system integrating VoIP 911 calls via Asterisk PBX and IoT alarms via MQTT, streaming all incidents through Redpanda for real-time dispatch to multiple terminals and command centers. Asterisk captures incoming calls from PSTN/VoIP networks, while Raspberry Pi MQTT clients relay house alarm sensors through Mosquitto broker—both feeding Redpanda's distributed event stream for low-latency fan-out to dispatch terminals, command center PCs, and monitoring dashboards. This architecture ensures incident data reaches multiple responders simultaneously while maintaining audit trails, reducing response time and eliminating single points of failure. Fork this diagram on Diagrams.so to customize incident routing, add additional sensor types, or integrate with your existing CAD/RMS systems. The shared infrastructure layer provides defense-in-depth with IAM, WAF, API Gateway, HA Redpanda cluster, Redis caching, encrypted recordings storage, and centralized monitoring—critical for 24/7 availability and compliance in emergency services.

People also ask

How do you design a real-time emergency dispatch system that handles both VoIP 911 calls and IoT alarm sensors with guaranteed delivery to multiple responders?

This diagram shows an event-driven architecture where Asterisk PBX captures 911 calls and Mosquitto MQTT brokers ingest IoT sensors, both publishing to a Redpanda event stream that fans out incidents to dispatch terminals and command centers simultaneously. The HA Redpanda cluster, API Gateway, IAM, and centralized logging ensure reliability, security, and auditability required for emergency servi
