C4 Component - CU-21 Verificar Estado del Peritaje
About This Architecture
C4 component diagram for CU-21 Verificar Estado del Peritaje—a layered inspection status verification system with React frontend, FastAPI REST controller, business logic service, and SQLAlchemy data access layer. User requests flow from the SPA through the PeritajeController to PeritajeService for validation and business rules, then to PeritajeDAO for database queries against PostgreSQL. This architecture demonstrates separation of concerns and testability, enabling secure, role-based access to inspection history and status details for buyers and sellers. Fork and customize this diagram on Diagrams.so to adapt the pattern for your own multi-tier applications.
People also ask
How should I structure a multi-tier inspection management system with React frontend and FastAPI backend?
This C4 component diagram shows a proven layered pattern: React SPA frontend calls FastAPI REST controller, which delegates to PeritajeService for business logic and validation, then to PeritajeDAO for database access. This separation enables testability, security, and maintainability.
- Domain:
- Software Architecture
- Audience:
- Backend engineers and solution architects designing inspection management systems with layered architectures
Generated by Diagrams.so — AI architecture diagram generator with native Draw.io output. Fork this diagram, remix it, or download as .drawio, PNG, or SVG.
