About This Architecture

Production Kubernetes microservices architecture featuring Ingress controller routing, multiple Deployments with Services, HorizontalPodAutoscalers for elastic scaling, and persistent storage via PVCs. Includes ConfigMaps and Secrets for configuration management. Fork this diagram on Diagrams.so to customize the service mesh topology or add sidecar containers for your microservices platform. Source: https://kubernetes.io/blog/

Kubernetes Microservices Architecture with Ingress & HPA
