GCP Web Application with Cloud CDN and Cloud SQL

GCPArchitecture

About This Architecture

Scalable web application architecture on Google Cloud with Cloud CDN for global content delivery, Cloud Load Balancing for traffic distribution, Compute Engine auto-scaling instance groups, Cloud SQL for relational data, Memorystore Redis for caching, and Cloud Storage for static assets. Cloud Armor provides WAF protection and Cloud Monitoring ensures full observability. Fork this diagram on Diagrams.so to customize the compute tier or add Cloud Run for serverless components in your web application. Source: https://docs.cloud.google.com/architecture
