About This Architecture

Event-driven serverless architecture using Azure Functions, Event Grid, Service Bus, and Cosmos DB for scalable event processing. Includes API Management for external access, Azure AD for authentication, and Application Insights for distributed tracing across the serverless components. Fork this diagram on Diagrams.so to customize the event sources or add additional Function App consumers for your event-driven workload. Source: https://github.com/lukemurraynz/awesome-azure-architecture
