AWS Multi-Tier Web Application with Auto Scaling

AWSArchitecture

About This Architecture

Production multi-tier web application on AWS with CloudFront CDN, ALB for load balancing, EC2 Auto Scaling groups across multiple AZs, Aurora Multi-AZ for relational data, ElastiCache for session management, S3 for static assets, and Route 53 for DNS. Includes WAF for web protection and CloudWatch for auto-scaling metrics and alarms. Fork this diagram on Diagrams.so to customize the compute tier and database configuration for your web application workload. Source: https://docs.aws.amazon.com/prescriptive-guidance/
