AWS EKS Microservices with Service Mesh

AWSArchitecture

About This Architecture

Production EKS microservices architecture with Application Load Balancer ingress, multiple Kubernetes deployments across namespaces, ECR for container images, DynamoDB and Aurora for polyglot persistence, ElastiCache for caching, and CloudWatch Container Insights for observability. Includes IAM roles for service accounts and Secrets Manager for credential management. Fork this diagram on Diagrams.so to customize the service topology or add additional namespaces for your container workloads. Source: https://aws.amazon.com/architecture/

Architecture prompt

Generated by Diagrams.so — AI architecture diagram generator with native Draw.io output. Fork this diagram, remix it, or download as .drawio, PNG, or SVG.
