AWS CI/CD Pipeline with CodePipeline and ECS

AWSProcess-Flow

About This Architecture

Production CI/CD pipeline using CodeCommit for source control, CodeBuild for container image builds, CodePipeline for orchestration, and CodeDeploy blue/green deployments to ECS Fargate. Includes ECR for container registry, SNS for pipeline notifications, and CloudWatch for build monitoring. Follows AWS prescriptive guidance for automated deployment best practices. Fork this diagram on Diagrams.so to customize the deployment strategy and add approval stages for your release workflow. Source: https://docs.aws.amazon.com/prescriptive-guidance/
