About This Architecture

Enterprise-grade three-tier architecture spanning two Azure availability zones with perimeter security, application, and data tiers. Traffic flows from users through Front Door CDN and WAF Policy to Application Gateway, then through Azure Firewall to VMs and AKS node pools distributed across AZ1 and AZ2. PostgreSQL primary-standby replication, Azure Cache for Redis, and Blob Storage provide resilient data layer services monitored by Azure Monitor, Application Insights, and Log Analytics. Azure DevOps and GitHub drive CI/CD pipelines deploying containerized workloads via Container Registry to AKS clusters, with Key Vault securing credentials and Managed Identity enabling secure service authentication. Fork this diagram to customize subnets, scale sets, or add additional resource groups for your enterprise deployment.

People also ask

How do I design a highly available three-tier application on Azure with DDoS protection, WAF, AKS, and CI/CD integration across availability zones?

This diagram shows a complete enterprise Azure architecture: the perimeter VNet (10.1.0.0/16) provides DDoS Protection, WAF Policy, and Azure Firewall; the application VNet (10.2.0.0/16) spans two availability zones with AKS node pools and VMs; PostgreSQL primary-standby replication and Azure Cache for Redis ensure data resilience; and Azure DevOps pipelines automate container deployments via Cont
