AWS Microservices Platform - Single Region — AWS architecture diagram

About This Architecture

Multi-AZ AWS microservices platform with Route 53, CloudFront, and WAF protecting dual Application Load Balancers across two availability zones. Compute layer spans EC2 t3.large, ECS Fargate, and Lambda functions, each routing to resilient data stores: RDS Aurora with cross-AZ failover, DynamoDB with global tables, and ElastiCache Redis clusters. Management and observability integrate CloudWatch, X-Ray, CloudTrail, Config, Security Hub, GuardDuty, IAM, Secrets Manager, and KMS for comprehensive monitoring, compliance, and security posture. Fork this diagram to customize VPC CIDR blocks, instance types, or add additional regions for multi-region failover and disaster recovery.

People also ask

How do I design a highly available AWS microservices architecture across multiple availability zones with failover and security?

This diagram shows a production-ready single-region microservices platform spanning two AZs with Route 53 DNS, CloudFront CDN, WAF, and Shield Advanced at the edge, dual ALBs routing to EC2, ECS Fargate, and Lambda compute, and resilient data layer with RDS Aurora cross-AZ replication, DynamoDB global tables, and ElastiCache Redis. Integrated observability via CloudWatch, X-Ray, CloudTrail, Config
