Level 1 Data Flow Diagram for a hospital management system modeling four core processes: Patient Registration, Doctor Consultation, Laboratory Testing, and Billing System. Data flows from external entities (Patient, Doctor, Lab Technician) through processes that read and write to four data stores (Patient Records, Medical Records, Lab Reports, Billing Records). This DFD establishes the high-level workflow and data dependencies essential for designing a scalable, HIPAA-compliant AWS healthcare infrastructure. Fork this diagram on Diagrams.so to decompose processes further, add AWS services (RDS, S3, Lambda), or customize for your hospital's specific workflows. The optional lookup flows between data stores highlight cross-functional dependencies critical for system integration planning.

People also ask

What does a Level 1 Data Flow Diagram for a hospital management system look like?

This Level 1 DFD shows four main processes (Patient Registration, Doctor Consultation, Laboratory Testing, Billing System) connected to external entities (Patient, Doctor, Lab Technician) and four data stores (Patient Records, Medical Records, Lab Reports, Billing Records). Data flows between processes and stores illustrate how patient information moves through the hospital system, enabling archit
