About This Architecture

Car Parking Management System ERD models a relational schema with Vehicle, Parking_Slot, Parking_Record, Payment, and User entities. Vehicle records link to Parking_Record via vehicle_id, while Parking_Slot connects through slot_id; Parking_Record then references Payment records and User assignments. This normalized design enforces referential integrity, supports real-time occupancy tracking, duration calculation, and payment reconciliation—critical for SaaS parking platforms. Fork this diagram on Diagrams.so to customize zones, add rate tables, or extend with analytics views. The one-to-many relationships between slots and records enable efficient querying of historical occupancy and revenue per zone.

People also ask

What is the database schema structure for a parking management system?

This ERD defines a normalized relational schema where Vehicle and Parking_Slot entities connect to Parking_Record via foreign keys, enabling tracking of entry/exit times and duration. Parking_Record then links to Payment for billing, and User for operator assignment, supporting real-time occupancy queries and revenue reconciliation.
