About This Architecture

BDL Delivery Lifecycle ER diagram models the complete journey from business requirements through production deployment, spanning requirements, specifications, metadata, development tasks, testing, and release management. Data flows from BUSINESS_REQUIREMENT through FUNCTIONAL_SPECIFICATION and METADATA_OBJECT, branching into parallel JIRA_STORY and DEVELOPMENT_TASK workflows, converging at TESTING_UAT and RELEASE before final PRODUCTION_BDL deployment. This schema enforces traceability and governance across the entire BDL delivery chain, ensuring every production object links back to its originating requirement and captures lineage through DATA_LINEAGE relationships. Fork this diagram to customize for your organization's delivery process, add custom fields, or integrate with your metadata repository and CI/CD pipeline.

People also ask

How do I design a database schema to track business requirements through to production BDL deployment with full lineage and governance?

This BDL Delivery Lifecycle ER diagram provides a complete schema spanning BUSINESS_REQUIREMENT → FUNCTIONAL_SPECIFICATION → METADATA_OBJECT → DEVELOPMENT_TASK → TESTING_UAT → RELEASE → PRODUCTION_BDL, with DATA_LINEAGE capturing field-level transformations. Each entity includes foreign keys ensuring traceability from requirement to production, supporting governance audits and impact analysis.
