About This Architecture

Dedicated VRF enterprise APN architecture on TELUS mobile core with segregated cashless.apn and data.apn virtual routing instances. Traffic flows from 5G/LTE UE devices through TELUS PGW/SMF core, KORE DNS and RADIUS services, into a dedicated VRF with BGP peering to Cincinnati and Atlanta distribution gateways. Enterprise edge security includes WAF, firewalls with UE-to-UE isolation, VPN gateway encryption, and RADIUS-based fixed IP assignment from 10.0.0.0/13 pool. This architecture demonstrates network slicing best practices for mission-critical cashless payment systems requiring dedicated bandwidth, security boundaries, and geographic redundancy. Fork and customize this diagram on Diagrams.so to model your own carrier-grade APN topology with multi-site failover and compliance controls.

People also ask

How do you design a dedicated enterprise APN on TELUS mobile core with network slicing and geographic redundancy?

This diagram shows a dedicated VRF (cashless.apn) isolated from existing data.apn, with KORE RADIUS and DNS services managing fixed IP assignment from 10.0.0.0/13. BGP peering connects the VRF core router to Cincinnati and Atlanta distribution gateways, enabling multi-site failover with enterprise edge security including WAF, firewalls, and VPN encryption.
