About This Architecture

Smart Retail Store Monitoring ER model defines a normalized relational schema for tracking store locations, monitored areas, surveillance cameras, shelves, products, and AI-driven detection events. Data flows from LOJA (store) through AREA_MONITORADA (monitored areas) to CAMARA (cameras) and PRATELEIRA (shelves), with DETECCAO (detection) events triggering ALERTA (alerts) and RECOMENDACAO (recommendations). This architecture supports real-time inventory visibility, shelf monitoring, and automated restocking workflows across multi-location retail operations. Fork this diagram on Diagrams.so to customize entity relationships, add new attributes, or adapt it for your retail analytics platform. The model integrates employee FUNCIONARIO records with REPOSICAO (restocking) tasks, enabling staff accountability and operational efficiency tracking.

People also ask

What is the database schema for a smart retail store monitoring system with cameras and shelf tracking?

This ER model organizes retail monitoring data across 11 entities: LOJA (stores), AREA_MONITORADA (monitored zones), CAMARA (cameras), PRATELEIRA (shelves), PRODUTO (inventory), DETECCAO (AI events), ALERTA (alerts), RECOMENDACAO (actions), FUNCIONARIO (staff), REPOSICAO (restocking), and RELATORIO_IA (reports). Foreign keys link cameras to areas, shelves to areas, products to categories, and dete
