About This Architecture

Multi-cloud identity architecture combining Red Hat SSO on AWS EC2 with Oracle Autonomous Database on OCI for enterprise authentication. Internet traffic flows through Gateway Load Balancer, Network Firewall, and WAF before reaching an Application Load Balancer that distributes requests across four Red Hat SSO instances spanning three availability zones in us-east-1. All SSO instances connect to Oracle Autonomous Database in OCI, enabling centralized credential management and session persistence across hybrid cloud infrastructure. Fork this diagram to customize subnets, add additional regions, or integrate with your existing IAM policies and compliance frameworks. This architecture demonstrates defense-in-depth security with stateless SSO scaling and cross-cloud database resilience.

People also ask

How do I architect Red Hat SSO across AWS and OCI with Oracle Autonomous Database for enterprise authentication?

This diagram shows Red Hat SSO deployed on four EC2 instances across three AWS availability zones, fronted by an Application Load Balancer with Network Firewall and WAF protection. All SSO instances connect to Oracle Autonomous Database in OCI, enabling centralized identity management and session persistence across your hybrid cloud infrastructure.
