About This Architecture

MyeCX Azure Document Processing Platform orchestrates end-to-end document ingestion, AI-powered extraction, and intelligent formatting across desktop and mobile clients. Desktop and mobile users route through Azure Front Door with WAF protection, CDN acceleration, and Azure AD SSO before reaching API Management and Application Gateway, which distribute traffic to App Service web app and Container Apps mobile backend. Uploaded documents flow through Blob Storage landing zone, Logic Apps text conversion, and Azure Function blob triggers that invoke Azure Document Intelligence for text/image extraction and Azure AI Speech for audio processing, with results queued in Service Bus. Extracted content moves through Azure OpenAI Service for GPT-based formatting, Azure ML Studio for prompt management, and Event Grid-triggered approval workflows via Logic Apps, with real-time notifications via Notification Hubs and SignalR. Final formatted documents, metadata, and audit logs persist in Cosmos DB, Azure SQL Database, Blob Storage, and Data Lake Storage, with session caching via Azure Cache for Redis and observability through Application Insights, Azure Monitor, and Log Analytics. This architecture demonstrates defense-in-depth security (DDoS Protection, NSG, Managed Identity, Key Vault), multi-layer processing resilience, and enterprise-grade compliance for document workflows. Fork this diagram on Diagrams.so to customize subnets, add additional AI services, or adapt approval workflows for your organization's document governance requirements.

People also ask

How do you build a secure, scalable document processing platform on Azure with AI extraction and approval workflows?

MyeCX architecture uses Azure Front Door with WAF for ingress security, Azure Document Intelligence and AI Speech for content extraction, Azure OpenAI for intelligent formatting, and Event Grid-triggered Logic Apps for approval workflows. Multi-subnet design isolates presentation, ingestion, processing, and data tiers; Managed Identity and Key Vault enforce least-privilege access; Cosmos DB and Da
