About This Architecture

Hybrid AWS infrastructure integrating on-premises systems with Snowflake analytics via Direct Connect, VPC endpoints, and managed EC2 services. On-Prem System connects through DX Gateway to DataSpider, which ingests data into shared Amazon S3 and Snowflake through PrivateLink. HULFT DataCatalog and MotionBoard EC2 instances orchestrate metadata and visualization, backed by RDS and secure Snowflake connectivity via Interface VPC Endpoint. This architecture demonstrates secure, low-latency hybrid data pipelines with private connectivity to SaaS analytics without internet exposure. Fork and customize this diagram on Diagrams.so to adapt subnet sizing, add additional AZs, or integrate alternative data connectors.

People also ask

How do I securely connect on-premises systems to Snowflake on AWS without internet exposure?

This diagram shows a hybrid AWS architecture using AWS Direct Connect to link on-premises infrastructure to a VPC, then leveraging PrivateLink Interface VPC Endpoints for private Snowflake connectivity. EC2 instances running DataSpider, HULFT DataCatalog, and MotionBoard orchestrate data ingestion to S3 and analytics queries, eliminating public internet routes and reducing latency.
